5kW Inverter, 5.12kWh Battery and Four-Panel Solar Package
5kW Inverter, 5.12kWh Battery and Four-Panel Solar Package
The Solar Essentials Hybrid package is designed for customers who want a clear boundary between essential electricity and high-consumption appliances. It combines approximately 5kW of inverter capacity with 5.12kWh of nominal battery storage. The proposed 4-panel array is approximately 2.34kWp using 585W modules.
Quick package snapshot
| Specification | Planning value |
|---|---|
| Inverter class | 5kW |
| Nominal battery | 5.12kWh |
| Conservative usable AC energy | 3.69kWh |
| Solar array | 2.34kWp |
| Example average load | 800W |
| Approximate example runtime | 4.6 hours without solar |
| Estimated installed price before delivery | R52,000–R63,000 |
What this system can reasonably power
- whole-house LED lighting
- refrigerator and freezer
- televisions, routers, computers and office equipment
- selected bedroom, lounge and kitchen plugs
- kettle, microwave or washing machine individually
What should normally remain off the system
- electric geyser on battery power
- stove, oven and space heater
- tumble dryer and pool heater
- multiple high-power kitchen appliances together
Approximate battery runtime
| Average connected load | Planning runtime without solar |
|---|---|
| 400W | 9.2 hours |
| 600W | 6.1 hours |
| 1000W | 3.7 hours |
| 2000W | 1.8 hours |
These figures are not guarantees. Appliances cycle on and off, refrigerators have startup current, battery settings differ, and daytime solar can extend runtime substantially when conditions are favourable.
Example simultaneous-load plan
A sensible essential-load plan starts with the devices that protect communication, food, security and work. Keep LED lighting, Wi-Fi, a television, office equipment and refrigeration on controlled circuits. Use high-power appliances one at a time only where the inverter rating allows it. The system must never be treated as unlimited electricity simply because the inverter has spare capacity at one moment.
Core catalogue components
- Luxpower SNA5000 5KVA Inverter With Shoto 48V 5.12KWH Lithium-Ion Battery — core inverter or inverter-and-battery component
- NUR 12 Way Surface Distribution Board — example essential-load distribution-board enclosure
- NUR Earth Leakage Din Rail 63A DP 3kA — earth-leakage protection for a compatible final design
- Lear 2P Surge Arrester — AC surge-protection example
- Onesto 2P 160A Battery Disconnector — battery isolation example
- Onesto 125A Battery Fuse Link — battery fuse-link example; final rating must be selected by the installer
- WHL&E 50MM Black Battery Cable — battery-cable option; final size and length require design calculations
- WHL&E 35x8MM Lugs — cable lug for correctly prepared battery conductors
- WHL&E 585W JA Solar Panel — 4 panels proposed, subject to roof and string design
- WHL&E Solar Combiner Box 1 In 1 Out — combiner-box example selected according to the final string arrangement
- Chanan 2P 20-40ka 600V Surge Arrester DC — DC surge-protection example
- Suntree 25A 2P 550VDC Miniature Circuit Breaker — DC breaker example; voltage and current ratings must match the string
- 3.5M Unistrat Rail — panel-mounting rail
- WHL&E Roof Clamp Long — roof-clamp example; roof type must be confirmed
- WHL&E Mid Clamp — mid-clamp for adjacent modules
- Solar End Clamp — end-clamp for array edges
- WHL&E MC4 1-1 Male/Female Connector — MC4 connector set for compatible PV cabling
Distribution-board design
The electrician should decide whether the property needs a separate essential-load DB, a larger hybrid-load DB or a carefully labelled section within an existing compliant board. At minimum, the design should address:
- inverter AC input, AC output and bypass isolation
- earth-leakage or residual-current protection appropriate to the design
- separate breakers for lights, refrigeration and essential plugs
- AC surge protection and any required DC surge protection
- battery fuse protection and battery disconnection
- neutral and earth arrangement, bonding and test results
- permanent labels, a single-line diagram and customer handover instructions
Cost breakdown
| Cost area | Planning allowance |
|---|---|
| Core inverter or combo listed in the latest product export | R21,199 |
| Additional listed batteries | Included in core combo |
| Proposed solar panels | R7,000 |
| Protection, DB, mounting, cable and installation materials | R4,801–R10,801 |
| Electrician, commissioning, testing and CoC allowance | R14,000–R22,000 |
| Estimated installed package before delivery | R52,000–R63,000 |
Catalogue prices are taken from the latest supplied product export and can change. Quantities of rails, cable, connectors, breakers and clamps depend on the roof, string design, cable length and distribution board.
Pros
- clear package size and expected load boundary
- lithium battery platform with lower maintenance than traditional lead-acid storage
- pure sine-wave inverter equipment suitable for compatible electronics
- an upgrade path through solar panels, matched batteries or a larger inverter platform, depending on the model
Cons and limitations
- runtime falls quickly when kettles, heaters, geysers or other high-power appliances are used
- final battery and inverter compatibility must be confirmed by exact model and firmware
- roof space, shade and municipal or Eskom requirements can affect the final package
- a quoted inverter rating does not guarantee that every motor or compressor will start correctly
Warranty and handover
Warranty must be confirmed for the exact inverter, battery, solar-panel model and serial-number batch. Installation quality, battery settings, temperature, communication, internet monitoring, firmware and correct protection can affect warranty support. Keep the invoice, serial numbers, commissioning report, Certificate of Compliance and all installer documents.
Frequently asked questions
Can this package run a kettle?
The inverter may supply a typical kettle, but it should be used briefly and separately from other high-power appliances. Battery energy is still limited.
Can it run a refrigerator?
A refrigerator can often be included, but its running wattage is not the whole story. The electrician or system designer should check startup current, age, condition and the combined load at the moment the compressor starts.
Can I add panels or batteries later?
Often yes, but expansion must remain within the inverter’s input, battery-current and communication limits. Batteries should normally be matched by model, capacity, condition and manufacturer guidance.
Related solar guides
- Solar and battery package comparison
- 1kW mini essentials package
- 3.6kW essential home package
- 6kW balanced hybrid package
- 5kW family hybrid package
- 8kW large-home package
- Full off-grid system design
- Solar DB and protection guide
- Installation and delivery cost guide
Request a personalised solar, battery, installation and delivery quotation
Compliance and reference sources
- South African Government: electrical installation and Certificate of Compliance requirements
- Eskom: Small-Scale Embedded Generation registration guidance
Technical and registration requirements can change. The formal quotation and installer design must be checked against the requirements that apply to the customer’s electricity distributor, property, inverter model and installation date.
Planning note: package prices, product stock and installation allowances are indicative. Final design depends on the load schedule, cable routes, roof, earthing, distribution board, municipal or Eskom requirements and the exact equipment available when the quotation is issued.
