Solar and Battery Packages South Africa: From 1kW Backup to Full Off-Grid
Solar and Battery Packages in South Africa: From Essential Backup to Full Off-Grid Power
Choosing a solar system is not simply a matter of buying the largest inverter. A useful package must balance inverter power, battery capacity, solar generation, distribution-board design, protection equipment, installation quality and the customer’s real appliance use.
Simple analogy: the inverter is the width of the pipe, the battery is the size of the water tank, the solar panels refill the tank, and the distribution board controls which rooms and appliances are allowed to use the stored energy.
What each number means
- Inverter kilowatts: the approximate power that can be supplied at one time.
- Battery kilowatt-hours: the stored energy available over time.
- Solar kilowatt-peak: the panel array’s rated size under standard test conditions.
- Essential circuits: the lights and plugs deliberately selected for backup.
Package comparison
| Package | Inverter | Battery | Solar | Planning usable energy | Runtime at 400W | Estimated installed cost before delivery |
|---|---|---|---|---|---|---|
| Package 1: Mini Essentials | 1kW | 1.28kWh | Optional | 0.92kWh | 2.3 hours | R16,500–R21,000 |
| Package 2: Essential Home Plus | 3.6kW | 2.56kWh | Optional | 1.84kWh | 4.6 hours | R23,500–R29,000 |
| Package 3: Solar Essentials Hybrid | 5kW | 5.12kWh | 2.34kWp | 3.69kWh | 9.2 hours | R52,000–R63,000 |
| Package 4: Balanced 6kW Hybrid | 6kW | 5.12kWh | 3.51kWp | 3.69kWh | 9.2 hours | R61,000–R73,000 |
| Package 5: Family Hybrid | 5kW | 10.24kWh | 4.68kWp | 7.37kWh | 18.4 hours | R99,000–R117,000 |
| Package 6: Large-Home Hybrid | 8kW | 15.36kWh | 7.02kWp | 11.06kWh | 27.6 hours | R141,000–R169,000 |
The runtime figures use a conservative planning assumption of 80% usable battery depth and approximately 90% inverter efficiency, with no solar contribution. Actual runtime changes with appliance behaviour, battery settings, temperature, system losses and battery age.
What should normally be placed on essential backup?
- LED lighting, Wi-Fi, fibre equipment, alarms and CCTV
- televisions, computers and phone charging
- selected bedroom, lounge and office plugs
- refrigerator or freezer after startup-current assessment
- gate motor and garage equipment where compatible
What should normally remain outside a small essential-load DB?
- electric geysers, ovens and stoves
- space heaters and tumble dryers
- large air conditioners, pumps and compressors unless specifically designed for
- multiple kettles, microwaves and other high-power appliances at the same time
The kettle comparison
A 2kW kettle operated for five minutes uses approximately 0.17kWh. The first question is whether the inverter can supply 2kW. The second is how much of the battery that short boil consumes. A small 1.28kWh battery loses a meaningful portion of its stored energy to one boil, while a 10.24kWh bank absorbs the same event far more comfortably.
Core products available from Whitehouse
- Esener 1KW 12V Pro Inverter + Esener 1.28KW 12V Lithium-Ion Battery Combo — compact inverter-and-battery backup for light essential loads
- Esener 3.6KW 24V Pro Inverter + Esener 2.56KW 24V Lithium-Ion Battery Combo — higher-power backup for a fridge, office and selected plugs
- Luxpower SNA5000 5KVA Inverter With Shoto 48V 5.12KWH Lithium-Ion Battery — 5kW-class hybrid inverter and 5.12kWh battery combination
- Luxpower SNA6000 Hybrid Inverter With Volta 5.12KW Lithium Battery (New Gen) — 6kW-class hybrid inverter and battery combination
- Deye 5KW Hybrid Inverter — 5kW hybrid platform for a larger battery and solar array
- Deye 8KW Hybrid Inverter — 8kW hybrid platform for a large home
- WHL&E 585W JA Solar Panel — 585W solar module for residential and commercial arrays
Compliance before purchase
A permanently connected inverter or solar installation must be assessed and installed by a competent, legally registered electrical contractor. The final installation requires inspection, testing and the appropriate Certificate of Compliance. Grid-parallel systems must also follow the registration requirements of Eskom or the relevant municipality, using the exact inverter model and applicable test documentation.
Which package should you start with?
- Package 1: internet, lights, television and a laptop.
- Package 2: fridge, entertainment, office and selected plugs.
- Packages 3–4: hybrid solar for normal essential household circuits.
- Package 5: a family home needing longer overnight battery runtime.
- Package 6: a large home with controlled higher-power loads.
- Off-grid: a custom design with weather autonomy, generator strategy and strict load management.
Related solar guides
- 1kW mini essentials package
- 3.6kW essential home package
- 5kW solar essentials package
- 6kW balanced hybrid package
- 5kW family hybrid package
- 8kW large-home package
- Full off-grid system design
- Solar DB and protection guide
- Installation and delivery cost guide
Request a personalised solar, battery, installation and delivery quotation
Compliance and reference sources
- South African Government: electrical installation and Certificate of Compliance requirements
- Eskom: Small-Scale Embedded Generation registration guidance
Technical and registration requirements can change. The formal quotation and installer design must be checked against the requirements that apply to the customer’s electricity distributor, property, inverter model and installation date.
Planning note: package prices, product stock and installation allowances are indicative. Final design depends on the load schedule, cable routes, roof, earthing, distribution board, municipal or Eskom requirements and the exact equipment available when the quotation is issued.
