Short answer: solar surge protection needs a coordinated plan across the PV DC side, AC side, earthing and equipment layout. A surge protective device can limit transient overvoltage, but it does not replace circuit breakers, earth-leakage protection, correct earthing or a structural lightning-protection system where the building requires one.
Where can surges enter a solar system?
- Through the utility supply on the AC side.
- Through long PV conductors exposed to induced lightning voltages.
- Through communication and monitoring wiring.
- Through earth-potential differences during nearby lightning events.
- Through switching events inside the electrical network.
Protection device roles are different
| Device | Primary job | It does not replace |
|---|---|---|
| AC/DC SPD | Limits transient overvoltage | Breaker, RCD/earth leakage, earthing |
| Circuit breaker / fuse | Protects against overcurrent/fault current | SPD |
| Battery fuse | Protects high-current battery circuit | Battery BMS or disconnect |
| Earth leakage / RCD | Responds to leakage/shock conditions | SPD or overcurrent device unless combined |
| Isolator / disconnector | Provides safe isolation | Automatic fault protection |
| Lightning protection system | Manages direct-strike risk where required | Internal circuit protection |
Why DC-rated equipment matters
DC arcs behave differently from AC arcs. A device that is suitable for 230V AC is not automatically suitable for a high-voltage PV string. Use components with the correct DC voltage and interrupting ratings for the exact circuit.
Whitehouse stocks examples such as the Chanan 2P 20–40kA 600V DC Surge Arrester, CBI Surge Protection Device, Lear 2P Surge Arrester and DC fuse products including Onesto 20A 1000VDC Fuse.
What about the battery side?
The battery BMS is not a substitute for external fault protection. A lithium battery can supply very high current into a short circuit. Properly selected battery fusing and a disconnector provide another layer of protection and service isolation.
Current Whitehouse examples include the Onesto 2P 160A Battery Disconnector and battery fuse links in several ratings.
Why earthing must be part of the design
Surge devices work relative to an earthing/bonding system. Poor earth continuity, long conductor paths or incorrect bonding can reduce protection effectiveness. Earthing requirements vary by inverter topology and installation, so they should be designed—not improvised.
Can a surge protector guarantee protection from lightning?
No. An SPD reduces transient overvoltage within its design limits; it cannot guarantee survival of every direct or nearby strike. Sites with elevated lightning exposure may require broader lightning-risk assessment and structural protection.
Summer storms and South African systems
Solar systems should be designed for the local environment, including thunderstorms and utility disturbances. Protection is especially important because an inverter, battery and PV array represent a high-value connected electrical system rather than one appliance.
Type 1 and Type 2 SPD terminology
In broad IEC-style terminology, Type 1 SPDs are associated with installations where lightning-current protection is required, while Type 2 devices are commonly used to limit switching and induced transient overvoltages within distribution systems. The correct type and coordination depend on the site's lightning-protection arrangement, supply and installation standard. Do not select an SPD from the “kA” number alone.
SPD replacement and status indication
Many modular SPDs include a status window or replaceable cartridge. A device that has absorbed significant surges may no longer provide its original protection. Include SPD inspection in routine electrical maintenance and replace modules according to manufacturer instructions.
Surge protection buying checklist
- AC or DC application?
- Maximum continuous operating voltage?
- PV string maximum voltage?
- Required SPD type and discharge rating?
- Correct upstream/downstream fuse or breaker?
- Shortest practical earth/bonding path?
- Existing building lightning-protection system?
FAQ
Do I need surge protection on both AC and DC?
Many PV systems use protection on both sides, but the exact devices and type depend on the installation and inverter architecture.
Does an SPD stop my breaker from tripping?
No. Breakers and SPDs handle different electrical events.
Can I install a DIN-rail SPD myself?
Work inside DBs and live electrical systems should be done by suitably qualified persons and tested as part of the installation.
